| Weight | 43 lbs |
|---|---|
| Brand | |
| Color | |
| Cooktop Type | Radiant Smoothtop |
| Depth | 21 1/2" |
| Height | |
| Type | |
| Width | 29 7/8" |
Product Documents
GE Café™ Series CEP90301TBB 30″ TOUCH-CONTROL ELECTRIC COOKTOP
Price range: $1,091.00 through $1,798.00
| WiFi Connect | Built-In |
| Filler trim kit | JXTR32B |
| Cooktop Burner Type | 5 Ribbon Smoothtop |
| Melt Setting | Yes |
| Fuel Type | Electric |
| Element – Left Front | 7″ 1500W |
| Indicator Lights | 5 Hot Surface Red Surface Element “ON” |
| Element – Right Front | 8″/5″ 2200W Dual |
| Control Location | Front Center |
| Cooktop Type | Radiant Smoothtop |
| Cooktop Surface | |
| Cooktop Control Features | All-Off Control Control Lock Capability Custom Settings Keep-Warm Setting Kitchen timer LED Light level adjustment Melt Setting Sound adjustment Sync-Burners Capability |
| WiFi Enabled Features | Bluetooth Pairing – Chef Connect with Hoods/OTRs and HestenCue Pans (HMI) Guided cooking with HestanCue Pans (App) Interfaces with SmartHQ App Precision cooking with HestanCue Pans (HMI and App) |
| Element – Left Rear | 7″ 1500W (Keep Warm) |
| Control Type | Electronic Glide Touch |
| Element – Center | 9″/7″/5″ 3000W Tri-ring Power Boil |
| Element – Right Rear | 6″ 1200W (Melt) |
| Product Type | Cooktop |
Appearance
- Color Appearance: Stainless Steel on Black
- Frameless: Yes
- Control Knobs: Stainless Steel Appearance
Weights & Dimensions
- Approximate Shipping Weight: 48 lb
- Cabinet Width: 30 in
- Cooktop Size: 30 in
- Cutout Dimensions (Width x Depth) (In.): 28-1/2 x 19-5/8
- Net Weight: 42 lb
- Overall Depth: 20 7/8 in
- Overall Height: 5 9/16 in
- Overall Width: 29 3/4 in
Power / Ratings
- Max. Connected Load (kW) at 208V: 7.1
- Max. Connected Load (kW) at 240V: 9.4
- Max. Current Draw (Amps) at 208V: 33.9
- Max. Current Draw (Amps) at 240V: 39.2
- Recommended Circuit Breaker (Amps) at 208V: 40
- Recommended Circuit Breaker (Amps) at 240V: 40
Warranty
- Parts Warranty: Limited 1-year entire appliance
- Labor Warranty: Limited 1-year entire appliance
- Warranty Notes: See written warranty for full details
